woodworking machinery
Particle board, MDF, OSB & Solid wood plants / segments / single machines
191404020 PB Pressing line
|
Make: SCHENCK / BECKER VAN HÜLLEN |
|
||
|
Model: Flexopan Year: 1978, modified 1990 |
|
||
|
Capacity: up to 300 m3/day |
|
||
|
Panel width: 2.100 - 2.140 mm Panel length: 5.130 mm |
|||
|
Thickness: 8-38 mm |
|
||
191303 PB Pressing line
|
Make: PAGNONI Model: MO , 10 daylights Year: 1965, modified 1978 & 2008 Capacity: 240 m3 per day Thickness range: 6 – 45 mm Board sizes at press exit: •width : 1220 mm – 1850 mm •length: 2440 mm – 3700 mm |
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
191302 MDF Pressing line
|
Make: KÜSTERS/DIEFFENBACHER Model: CPS - continuous pressing line Year: 1981, modified 2003-2012 Capacity: 300-760 m3 per day Thickness range: 3 – 25 mm Board sizes at press exit: •width : 1830 mm – 2200 mm •length: 4200 mm – 6100 mm |
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
1915101901 MDF Pressing line
|
Make: SUNDS/DIEFFENBACHER Model: CPS - continuous pressing line Year: 1989, modified 1997/2005/2006/2007 Capacity: 390 m3 per day Thickness range: 3 – 20 mm Board sizes at press exit: •width : 1830 mm – 2440 mm •length: 4940 mm |
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
111403180 WEISS biomas energy plant
|
Make: WEISS Year: 1989 Max. total power: 25 MW Biomas power : 14 MW Wood dust power: 14 MW Oil power: 14 MW Hot gas generator: 900 deg. C, 25 MW
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
111403181 Drum dryer
|
Make: PROMILL Year: 1989 Water eveporation: 25 t/h No. of cycIclones: 8 Inlet temperature: 500 deg. C
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
3015101402 Short cycle lamination line 4’
|
Make: SIEMPELKAMP Model: down stroke press Heating platen size: 5200x1400 mm Spec. Press pressure: 500 N/cm2 Capacity: up to 100 cycles/h Board format: 2440x1220-1250 mm x 2 pcs. Heating media: thermal oil Operating temperature: 200 – 220 deg C Heat consumption: 320.000 kcal/h Paper lifts: 2 pcs Stacks for raw panels: 2 pcs Time to reach 150 N/cm2: 1.6 sec. |
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
301301 Short cycle lamination line
|
Make: SIEMPELKAMP Model: KT Year: 1978 Downtime standard: 23 sec. Panel width: 1860 - 2210 mm Panel length: 3760 - 6100 mm Pressing system: upstroke Thickness: 5 - 40 mm
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
3015040701 Short cycle lamination line
|
Make: RAUTE OY Year: 1996 Heating platen size: 5230 x 1830 mm Capacity: 88 cycles/h Panel width max.: 1860 mm Panel length: 2440 - 2500 mm Thickness: 6 - 38 mm Pressing system: downstroke Quantity of films: 3+1
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
1915022002 CPL line
|
Make: HYMEN Model: MCF 2103 Year: 1978 Capacity: 17.000.000 m2 per year Thickness range: 4-40 mm Panel width: 1830 - 2050 mm Panel length: 2440 - 4880 mm
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
40130701 Impregnation line
|
Make: BABCOOCK Year: 1983 Max. stacking length: 6200 mm Max. working width: 2300 mm Max. throughput speed 50 m/min (average 80 gr paper 35m/min) Heat demand: 950.000 Kcal/h Composition: impregnator, coating machine, cooler & stacker and recovery
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
4015022003 Impregnation line
|
Make: VITS Model: PROLINE Year: 1991 Max. working width produced on line: 1830 mm Max. throughput speed 47 m/min by melamine Heat demand: 950.000 Kcal/h 3 Baths
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
1965 Pre Press
|
Make: SIEMPELKAMP Model: Pre -Press Year: 1999 Forming path height: up to 1400 mm Forming path width: up to 2250 mm No. of press cylinders: 4 Impetust: 900 kN
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
991403180 Thermal oil heater
|
Make: BAY Model: HG 4000 Year: 1990 Flow temperature: 300 deg. C Fuel: fuel oil Burner: Weishaupt WKL
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
119150716 PAL Screens
|
Make: PAL Model: DP-3P/5-32180 DMS/S Year: 2001 Operated until: 2011 Capacity: 20 t/h atro Quantity: 2 pieces
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|
||
